Category

The sleeve anchors allow it to anchor into concrete, brick and block. Sleeve anchors work when you insert it into a predrilled hole in the base material and then turn the nut to pull the working end of the sleeve anchor up through the sleeve. The anchor is then expanded and anchored securely in the concrete, brick or block. The anchors are available in zinc plated and stainless steel. Sleeve anchors come fully assembled and ready to use.

SIZE

M6X50, M8X60, M10X70, M12X90, M16X110, M20X150, etc

Finish

Galvanized

Measurement System

Metric

Material

Carbon Steel

Capacity

100 lbs

Carbon Steel Heavy Duty Sleeve Anchor

H496f9cdf5b9e4aa685fe2a5e48f87bb94

H8b2dcfebb88545cca0c0bbcf67338b90i

Hf3eb3cf833a64dd080082e1e57013189m

H0a7e586025f245529d8d35c6649a9689L

1.Carbon Steel Heavy Duty Sleeve Anchor with O Hook Description:

The sleeve anchors allow it to anchor into concrete, brick and block. Sleeve anchors work when you insert it into a predrilled hole in the base material and then turn the nut to pull the working end of the sleeve anchor up through the sleeve. The anchor is then expanded and anchored securely in the concrete, brick or block. The anchors are available in zinc plated and stainless steel. Sleeve anchors come fully assembled and ready to use.

Other Used Names
Sleeve thunderbolts, bolt sleeve anchors, masonry anchors.

1 79628

2.Main Features:

Category Sleeve Anchor
Material Carbon Steel, Stainless steel
Thread Type Metric, American, Unified
Surface treatment Zinc Plated, Hot Dip Glavanized, Acid cleaning
Appearance Bolt, Hex Nut & Washer, Flange Nut, Concial Nut, O Hook, C Hook, L Type, Double Sleeve, with Wing

3.Carbon Steel Heavy Duty Sleeve Anchor with O Hook Parameters:

Dia.X Length Max. Fixture Thickness (mm) Pull out Load (Kgs)
M6.5X18 3 800
M6.5X25 4
M6.5X36 8
M6.5X56 26
M6.5X75 45
M8X40 8 1200
M8X65 35
M8X85 55
M10X40 6 1700
M10X50 12
M10X60 15
M10X75 27
M10X100 62
M12X60 15 2500
M12X75 27
M12X100 52
M12X120 70
M12X130 80
M16X65 20 3700
M16X110 65
M16X145 100
M20X75 25 5100
M20X107 57
M20X151 101
Dia.X Length Max. Fixture Thickness (mm) Pull out Load (Kgs)
1/4X1-3/8 1″ 1200
1/4X2-1/4 1″
1/4X3 1″
1/4X4 1″
5/16X1-1/2 1″ 1700
5/16X2-1/2 1″
3/8X1-7/8 1-1/4″ 2700
3/8X3 1-1/4″
3/8X4 1-1/4″
3/8X5 1-1/4″
3/8X6 1-1/4″
1/2X2-1/4 1-1/2″ 4300
1/2X3 1-1/2″
1/2X4 1-1/2″
1/2X6 1-1/2″
5/8X2-1/4 2″ 6100
5/8X3 2″
5/8X4-1/4 2″
5/8X5-3/4 2″
5/8X6 2″
3/4X2-1/2 2″ 7800
3/4X4-1/4 2″
3/4X5-1/2 2″
3/4X6-1/4 2″

If the product is non standard and need customized, please contact us for more details.

FREQUENTLY ASKED QUESTIONS

🏭 1. Company & Factory Profile

  • Q1: Are you a trading company or a direct manufacturer?

    A: We are a direct manufacturer. Our production facility is located in Handan City, Hebei Province—the main fasteners manufacturing hub in China—delivering factory-direct pricing and full quality control.

  • Q2: Where is your factory located and how can I visit?

    A: Our factory is located in Handan City, Hebei Province, China. You can fly directly to Handan Airport (HDG) or take the high-speed bullet train to Handan East Station. We can arrange pick-up service from the station or local hotels.

  • Q3: How many years of experience do you have in manufacturing anchor fasteners?

    A: We have over 15 years of specialized experience in cold-forging and manufacturing concrete expansion anchors and industrial hardware.

  • Q4: What certifications does your factory or products hold?

    A: Our factory operates under ISO9001 quality management standards, and our anchor products comply with international standards including CE certifications.

  • Q5: Do you attend international trade fairs?

    A: Yes, we regularly participate in major domestic and international hardware exhibitions, including the Canton Fair (Guangzhou), Shanghai Fastener Expo, and overseas industry trade shows.

🛠️ 2. Products, Standards & Customization

  • Q6: What manufacturing standards do your anchors follow?

    A: We manufacture anchors in strict accordance with DIN, ISO, ANSI/ASME, BSI, and GB international standard specifications, offering both Metric and Imperial size ranges.

  • Q7: Do you provide OEM and ODM customization services?

    A: Yes, we offer comprehensive OEM and ODM services. We can manufacture custom anchor dimensions, specialized sleeve designs, or private-label branded packaging according to your drawings and specifications.

  • Q8: What key applications are your anchor products designed for?

    A: Our anchors are widely used in heavy-duty concrete fastening, structural steelwork, curtain wall installation, HVAC ducting, piping suspension, machinery mounting, and general construction.

  • Q9: How are your products typically packaged for export?

    A: Standard packaging includes inner small boxes, strong master cartons, and fumigation-free wooden pallets. Custom private-label inner boxes and customized carton designs are fully supported for OEM clients.

📦 3. Samples, Ordering & MOQ

  • Q10: Do you provide free samples for quality evaluation?

    A: Yes, we provide free physical samples for standard anchor sizes. Buyers only need to cover the courier freight costs (which can be refunded upon formal order confirmation). For custom non-standard items, a sample tooling fee may apply.

  • Q11: What is your Minimum Order Quantity (MOQ)?

    A: Our general MOQ is 1,000 pcs for large-size anchors and 3,000–5,000 pcs for standard small sizes. We can also accommodate flexible trial order quantities depending on current stock and production scheduling.

  • Q12: What is your standard production lead time?

    A: Standard lead time is typically 25 to 35 days upon deposit receipt and order confirmation, depending on order volume and surface finishing requirements.

💳 4. Payment Terms & Logistics Services

  • Q13: What are your accepted payment terms?

    A: We primary accept T/T (Telegraphic Transfer) and L/C at sight. Flexible credit terms (such as D/P or OA) can be evaluated for long-term strategic partners.

  • Q14: Can we consolidate goods from our other Chinese suppliers at your factory?

    A: Yes, we offer complimentary warehouse consolidation services. Your other suppliers can ship goods to our factory, and we will handle joint container loading and export documentation for you.

  • Q15: Can you assist with paying other suppliers or delivering cargo to our designated warehouse in China?

    A: Yes, for our established customers, we provide value-added procurement support, including domestic warehouse delivery within China and multi-supplier payment handling upon request.
